- Automatic float switch to prevent dry running
- iSensor control monitors the system pressure and flow in real time
- Built in non-return valve to prevent back flow and ensures shut-down at minimal flow levels.
- Industrial motor for best performance and longevity in operation
- Slotted strainer design at suction
- Dual mechanical seals
- Stainless steel body
- 240V single phase motor with in-built thermal protection
- 2.5 Bar Cut-in pressure
- Household Booster Pump
- Gardening
- Drinking water
- Laundry
- Bathroom
- Rainwater harvesting
- Kitchen
- Irrigation
- Watermark approved
- Does not require regular maintenance
- No electrical consumption - No electronic components
- Solid brass construction - Fully weatherproof - Built to last
- Suitable for any pressure pump with sufficient head pressure
- Can be mounted in any position
- Built-in dual check valve for backflow prevention
- 2 Year warranty
Technical Specifications
| Brand | ClayTech Pumps |
| Product Type | Submersible Rainwater Pump |
| Approval | Approved For Drinking Water |
| Max Flow (L/min) | 100 |
| Max Head (m) | 35 |
| Port Size Outlet | 1" |
| Taps | 6 |
| Volts | 240 |
| Watts | 900 |
Description
Installed inside the rainwater tank, the submersible design ensures the pump installation is neat, secure and quiet with no requirement to install additional protection against the elements.
It is intended for use in household applications for the automatic supply of clean water which contains no fibres.
Features
Applications:
AcquaSaver Water Diversion Valve - 3/4 Inches
Hydraulically Operated. Solid Brass Construction. Built-in Dual Check Valves. Prioritise the use of rainwater over mains water and will automatically switch over to mains water in the event of the rainwater tank running low.
The AcquaSaver® Valve is a fully automatic mechanical rainwater/mains water changeover device designed for pressure pump supply systems for harvesting rainwater for the toilet, laundry and household applications with automatic mains backup.
Operation
The AcquaSaver® Valve will always prioritize the use of rainwater over mains water when rainwater is available and will automatically switch over to mains water in the event of the rainwater tank running low or electrical failure
When rainwater has been replenished or power has been restored to the pump, the AcquaSaver valve will automatically prioritize back to rainwater.
The pump is only active when rainwater is being drawn from the water tank, it does not operate when the AcquaSaver Valve has switched to mains position.
The pump controller starts and stops the pump when it detects a demand - for example flushing a toilet or using a washing machine.
The operating mechanism of the AcquaSaver Valve is a unique patent design, it works by hydraulic water pressure created by the pump to close one inlet fully before opening the other inlet. This ensures an extremely reliable mechanism using few moving parts and no electronic components and no energy consumption.
| 3/4 Inch AcquaSaver - A2 Technical Data | |
|---|---|
| Acquasaver Max Mains Pressure | 500Kpa |
| Acquasaver Max Pump Pressure | 600Kpa |
| Acquasaver Max Flow Rate | 50 l/min |
| Acquasaver Outlet & Inlets | 3/4 " |
