Barcode:
4991644037346
Technical Specifications
| Brand | Ko-Ken |
| Product Type | Individual |
| Type | 50mm Long |
| Suitable For | Hand Tool |
| Drive | 3/8" |
| Length | 50mm |
| Series | Z Series |
| System of Measurement | Torx |
| Size | T45 |
| Style | Torx |
Description
COMPACT
2400MZ, 3400MZ and 4400MZ are designed 5-14mm shorter than standard 2400M, 3400M and 4400M. Ideal for working in confined and tight areas.
TOLERANCE - Hexagon Opening
Ko-ken standard sockets are manufactured according to DIN/ISO standards. The tolerances of Z-Series sockets are precisely controlled to achieve a more positive fit between bolt and socket.
TOLERANCE - Square Drive
Manufacturing tolerance of Male and Female Square are precisely controlled to achieve a more secure fit between Socket and Handle.
BALL HOLDING GROOVE
Original Ball Holding system is applied on Z-series. This mechanism gives secure connection between Socket and Handle.
RATCHET HANDLE
Smaller head with 36 tooth gear and light ratchet movement allow working in narrow space and confined areas.
Specifications
| Part Number | |
|---|---|
| MPN | KO3025Z50T45H |
| Drive | |
|---|---|
| Drive | 3/8 Inch Drive |
| Brand | |
|---|---|
| Brand | KO-KEN |
