MPN:
675600006AF
Barcode:
4049002097171
- Powered hydraulic hand tool for crimping turned pin and socket contacts
- 20 kN pressure
- Crimp cycle 2.8 seconds
- Approx. 300 crimps achievable on one battery charge (with average load)
- Charging time <30 min for lithium-ion battery
- 4/8 indent crimping units usable, rotates by 360°
- Indent positioning precision to 1/100 mm
- Integrated wear monitoring
- Recalibration function
Crimping unit, indenters fulfill requirements of AS22520 /1-01
6756 0000 6
| Part No. | 6756 0000 6 |
|---|---|
| EAN | 4049002097171 |
| Weight | 1,060 g |
| Dimension | 160 x 130 x 60 mm |
| Capacity | 0.14 – 6.0 mm² / AWG 26 – 12 |
| Max. contact Ø | 5.5 mm |
Specifications
| Brand | RENNSTEIG |
