MPN:
975218
Barcode:
4003773026839
- The ingenious lever transmission reduces the handforce up to 30% compared with regular crimping pliers
- Consistently high crimping quality due to precision dies and ratchet mechanism (unlockable)
- Precise, factory calibrated crimping pressure
- Two-hand operation for easy crimping of large conductor diameters
- Easy handling as a result of well balanced centre of gravity, angled head and ergonomically shaped handles
- Crimping die is not exchangeable
| Technical Description | |
|---|---|
| Article No. | 97 52 18 |
| EAN | 4003773026839 |
| Pliers | Burnished |
| Head | Burnished |
| Handles | With non-slip plastic coating |
| Weight | 571 g |
| Dimensions | 250 x 78 x 26 mm |
| REACH compliant | Contains SVHC |
| RoHS compliant | Not applicable |
| Technical Description | |
|---|---|
| Application | Twin wire ferrules 2x6 / 2x10 / 2x16 mm² |
| Capacity in square millimetres | 6 / 10 / 16 mm² |
| Number of crimp profiles | 3 |
| AWG | 10 / 8 / 6 |
| AWG | 2 x 10 / 2 x 8 / 2 x 6 |
Specifications
| Brand | KNIPEX |
