- DIN 6450 Die forged.
- Used to drive pins for affixing a fixture to a rotating shaft.
Individual Sizes (Available Separately):
| Item No. | S (mm) | S1 (mm) | L (mm) | Be-Cu (g) | Al-Cu (g) |
|---|---|---|---|---|---|
| CB223B-1003 | 3 | 9 | 110 | 20 | 15 |
| CB223B-1004 | 4 | 10 | 110 | 57 | 50 |
| CB223B-1006 | 6 | 12 | 115 | 105 | 95 |
| CB223B-1008 | 8 | 14 | 120 | 130 | 115 |
| CB223B-1010 | 10 | 16 | 145 | 200 | 180 |
| CB223B-1012 | 12 | 18 | 160 | 280 | 260 |
| CB223B-1014 | 14 | 20 | 180 | 410 | 380 |
| CB223B-1016 | 16 | 24 | 200 | 640 | 600 |
| CB223B-1018 | 18 | 30 | 225 | 1070 | 960 |
| CB223B-1020 | 20 | 32 | 225 | 1230 | 1110 |
Specifications
| Part Number | |
|---|---|
| MPN | CB223B-1016 |
| Brand | |
|---|---|
| Brand | T&E TOOLS |
